Soft Flow Dyeing Machine

Soft Flow Dyeing Machine Price And Quantity

• Minimum Order Quantity 1 Unit
• Price 1450000 INR/Unit

Soft Flow Dyeing Machine Product Specifications

• Pump Type High efficiency centrifugal pump
• Applicable Material Cotton, Polyester, Viscose, Blends
• Features Low liquor ratio, energy saving, uniform dyeing, robust stainless steel construction, auto dosing, auto drain, programmable cycles, safety interlocks, insulation for thermal efficiency
• Speed Variable, Adjustable via Control Panel
• Volume Depending on model and tank size (e.g. ~2 m3 to 10 m3)
• Control Type PLC based microprocessor automatic control
• Manufacturing Year 2024
• No Of Chamber Single/Double as per model
• Temperature Range Room temperature to 140C
• Fabric width Tubular or open width up to 2400 mm
• Power 7.5 kW - 15 kW (model dependent)
• Machine Type Automatic/ Semi-Automatic
• Fabric Type Woven and Knitted Fabrics
• Usage & Applications Used for dyeing processes in textile industry for variety of fabrics and blended materials
• Type Soft Flow Dyeing Machine
• Voltage 380V / 415V (Three Phase, 50/60 Hz)
• Capacity 50 kg to 500 kg per batch
• Weight Approx. 2500-3800 kg (depending on model/capacity)
• Dimension (L*W*H) 4000 mm x 1800 mm x 2500 mm (standard size, may vary)
• Condition New

• Mounting Type Floor mounted
• Safety Devices Pressure relief valve, over-temperature protection
• Noise Level Low noise operation (<75 dB)
• After Sales Service Available on site / Remote support
• Color Touch Screen Display Optional
• Auto Dosing System Available (on request)
• Manhole/Observation Port Yes, for inspection
• Circulation Pump Motor Heavy duty, high efficiency
• Heating System Steam/Direct/Indirect
• Max Loading Ratio 1:5 to 1:8 (fabric weight to liquor)
• Max Working Pressure 3.5 Bar
• Material of Construction Stainless Steel 316/304
• Drainage System Automatic and Manual

Soft Flow Dyeing Machine Trade Information

• Supply Ability 1 Unit Per Month
• Delivery Time 30 Days
