Long Jet Dyeing Machine Top Tube

Name: Long Jet Dyeing Machine Top Tube
Brand: APEX ENGINEERS
Price: 1150000 INR
Availability: InStock

1150000 INR/Unit

Get a Price/Quote

Product Details:

Volume 800 Liters
Manufacturing Year 2023
Weight Approx. 2500 kg
Type Long Jet Dyeing Machine Top Tube
Machine Type Automatic Jet Dyeing Machine
Usage & Applications Textile dyeing for knitted, woven, and blended fabrics
Fabric width Up to 2400 mm
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Long Jet Dyeing Machine Top Tube Price And Quantity

Minimum Order Quantity 1 Unit
Price 1150000 INR/Unit

Long Jet Dyeing Machine Top Tube Product Specifications

Applicable Material Cotton, Polyester, Blends, Viscose, Wool, Nylon
Manufacturing Year 2023
Power 15 kW
Speed Adjustable (Up to 350 m/min)
Weight Approx. 2500 kg
Volume 800 Liters
Capacity 100 kg to 500 kg per batch
Type Long Jet Dyeing Machine Top Tube
Dimension (L*W*H) 6000 mm x 1500 mm x 2500 mm
Temperature Range Up to 140 C
Fabric Type Knitted and Woven Fabrics
Control Type PLC Automatic Control Panel
Machine Type Automatic Jet Dyeing Machine
Fabric width Up to 2400 mm
Pump Type Centrifugal Stainless Steel Pump
No Of Chamber Single / Double Available
Features High efficiency, Low liquor ratio, Energy saving, Stainless steel construction, Easy maintenance
Voltage 415V / 3 Phase / 50 Hz
Condition New
Usage & Applications Textile dyeing for knitted, woven, and blended fabrics

Insulation Type Thermal insulation with outer cladding
Safety System Over-temperature & over-pressure alarms, Safety interlocks
Door Type Manual or Pneumatically operated
Heating System Steam injectors / Electric heater
Color Kitchen Integrated dye solution pre-mixer
Material of Construction SS 316 / SS 304 Stainless Steel
Jet Nozzle Interchangeable for different fabric types
Installation Floor mounted with robust support
Design Pressure Up to 4 bar
Liquor Ratio 1:3.5 to 1:5
Service Requirements Compressed air, Soft water supply, Electric connection
Draining System Automatic Pneumatic Control
Water Consumption Low water usage per cycle
Process Control Fully automatic with program memory & fault diagnostics

Long Jet Dyeing Machine Top Tube Trade Information

Supply Ability 2 Unit Per Month
Delivery Time 30 Days
